• In the carrier mechanism and top guide, used heavy-duty rail with soft-closing.
• Carrying capacity is 80 kg max.
• Product length can be adjusted according to the height of the cabinet.
• Door can be adjustable two axes via door connections parts.
• Three different size of baskets are appropriate to the width of the cabinet.(Other sizes can be customized)
• Baskets can be fixed to desired hight of the frame with plastic hangers.
• Carrying mechanism, guide and frame are grey painted, basket frames chrome plated.
• Alternatively in wire basket/ wooden bottom basket/ glass basket available.
Name | Item | Cabinet | Depth x Width x Height | Description | Material | Color |
Tall Unit Basket | PTJ012H-300 | 300mm | 480 x 250 x (1150-1350) mm | 4 Layers | Iron | Silver grey+chrome |
Tall Unit Basket | PTJ012H | 400mm | 450 x 350 x (1150-1350) mm | 4 Layers | Iron | Silver grey+chrome |
Tall Unit Basket | PTJ012H-500 | 500mm | 450 x 480 x (1150-1350) mm | 4 Layers | Iron | Silver grey+chrome |
Tall Unit Basket | PTJ012F-300 | 300mm | 480 x 250 x (1400-1700) mm | 5 Layers | Iron | Silver grey+chrome |
Tall Unit Basket | PTJ012F | 400mm | 480 x 350 x (1400-1700) mm | 5 Layers | Iron | Silver grey+chrome |
Tall Unit Basket | PTJ012F-500 | 500mm | 450 x 480 x (1400-1700) mm | 5 Layers | Iron | Silver grey+chrome |
Tall Unit Basket | PTJ012D | 400mm | 480 x 350 x (1700-2000) mm | 6 Layers | Iron | Silver grey+chrome |
